\(R_t\) estimation and the renewal equation

Introduction

In the last session we used the idea of convolutions as a way to interpret individual time delays at a population level. In that session, we linked symptom onsets back to infections. Now we want to link infections themselves together over time, knowing that current infections were infected by past infections. Correctly capturing this transmission process is crucial to modelling infections in the present and future.

Slides

Objectives

The aim of this session is to introduce the renewal equation as an infection generating process, and to show how it can be used to estimate a time-varying reproduction number.

Source file

The source file of this session is located at sessions/R-estimation-and-the-renewal-equation.qmd.

Libraries used

In this session we will use the nfidd package to load a data set of infection times and access stan models and helper functions, the dplyr and tidyr packages for data wrangling, ggplot2 library for plotting, and the tidybayes package for extracting results of the inference.

library("nfidd")
library("dplyr")
library("tidyr")
library("ggplot2")
library("tidybayes")
Tip

The best way to interact with the material is via the Visual Editor of RStudio.

Initialisation

We set a random seed for reproducibility. Setting this ensures that you should get exactly the same results on your computer as we do. We also set an option that makes cmdstanr show line numbers when printing model code. This is not strictly necessary but will help us talk about the models.

set.seed(123)
options(cmdstanr_print_line_numbers = TRUE)

The renewal equation as a process model for infectious diseases

In this session we introduce modelling the infection process itself, in addition to modelling observation processes.

Recall that in the session on convolutions we tried to estimate the number of infections. In doing so we assumed that infections every day were independently identically distributed and determined only by the number of symptom onsets that they caused. In reality, however, we know that infections are not independent. Because infection is dependent on a pathogen being transmitted from one individual to another, we expect infections on any day to depend on existing infections, that is the number of individuals that became infectious in the recent past. We now express this relationship via the renewal equation, which links these recent infections to the number of new infections expected on any day via the reproduction number \(R_t\).

Remember that this is a more general concept than the basic reproduction number \(R_0\) which represents the average number of secondary infections caused by a single infectious individual in a completely susceptible population.

The reproduction number \(R_t\) (sometimes called the effective reproduction number) more generally describes the average number of secondary infections caused by a single infectious individual and can vary in time and space as a function of differences in population level susceptibility, changes in behaviour, policy, seasonality etc.

In most mechanistic models of infectious diseases (starting with the simplest SIR model), \(R_t\) arises out of a combination of parameters and variables representing the system state, for example in a simple SIR model it can be calculated as \(R_0 S/N\) where \(S\) is the current number of susceptibles in the population of size \(N\). By fitting such models to data it is then possible to calculate the value of \(R_t\) at any point in time.

The renewal equation represents a more general model which includes the SIR model as a special case. In its basic form it makes no assumption about the specific processes that cause \(R_t\) to have a certain value and/or change over time, but instead it only relates the number of infected people in the population, the current value of the reproduction number and a delay distribution that represents the timings of when individuals infect others relative to when they themselves became infected, the so-called generation time. Mathematically, it can be written as

\[ I_t = R_t \sum_{i=1}^{g_\mathrm{max}} I_{t-i} g_i \]

Here, \(I_t\) is the number of infected individuals on day \(t\), \(R_t\) is the current value of the reproduction number and \(g_i\) is the probability of a secondary infection occurring \(i\) days after the infector became infected themselves, with a maximum \(g_\mathrm{max}\). Remembering the session on convolutions you will be able to identify that the renewal equation represents a convolution of the infection time series with itself, with the delay distribution given by \(g_i\) and \(R_t\) representing a scaling that is being applied.

Discrete vs. continuous renewal equation

The equation shown above represents the discrete version of the reproduction number. Similar to discussions in the session on convolutions this can be interpreted as a discretised version of a continuous one where the sum is replaced by an integral and the generation time distribution is continuous. Note that in the discrete version we have started the sum at 1 and thus set \(g_0=0\) which will make calculations easier.

Instantaneous vs. case reproduction number

There are different definitions of the reproduction number that can be applied to the situation where it changes in time. As it is defined above it is also called the instantaneous reproduction number because any change affects all currently infectious individuals instantaneously. Another example of a definition is the case reproduction number, where changes affect individuals at the time that they are infected but then they have a constant reproduction number throughout their infectious period.

Stochastic vs. deterministic renewal equation

The version of the discrete renewal equation we wrote above is deterministic, i.e. knowing the number of infections up to a certain time point and the reproduction number we can work out exactly how many new infections we will see. Sometimes stochasticity is added where the equation above gives the expectation of \(I_t\) but there exists random variation around it. In this course we will only deal with the deterministic renewal equation.

Simulating an epidemic using the renewal equation

With the theory out of the way we now turn to simulating an epidemic using the renewal equation. We can use function included in the nfidd package to simulate the epidemic using the discrete renewal equation.

renewal
function (I0, R, gen_time)
{
    max_gen_time <- length(gen_time)
    times <- length(R)
    I <- c(I0, rep(0, times))
    for (t in 1:times) {
        first_index <- max(1, t - max_gen_time + 1)
        I_segment <- I[seq(first_index, t)]
        gen_pmf <- rev(gen_time[seq_len(t - first_index + 1)])
        I[t + 1] <- sum(I_segment * gen_pmf) * R[t]
    }
    return(I[-1])
}
<bytecode: 0x55a75a30bad8>
<environment: namespace:nfidd>
Take 10 minutes

Try to understand the renewal() function above. Compare it to the convolve_with_delay() function from the session on convolutions. How are they similar? Can you explain the key differences between the two? Try calling the function with a few different probability distributions and parameters. What kind of behaviours do you see depending on the values you put in?

Estimating \(R_t\) from a time series of infections

We now return to the time series of infections we used in the session on convolutions.

inf_ts <- make_daily_infections(infection_times)
head(inf_ts)
# A tibble: 6 × 2
  infection_day infections
          <dbl>      <int>
1             0          1
2             1          0
3             2          1
4             3          0
5             4          2
6             5          1

This creates the inf_ts data set which we can look at e.g. using

head(inf_ts)
# A tibble: 6 × 2
  infection_day infections
          <dbl>      <int>
1             0          1
2             1          0
3             2          1
4             3          0
5             4          2
6             5          1

We use a renewal equation model in stan to estimate the effective reproduction number throughout the outbreak. We assume that the generation time is gamma-distributed with mean 4 and standard deviation 2, with a maximum of 2 weeks (14 days). From this we can calculate that the parameters of the distribution are shape 4 and rate 1. We can use the censored_delay_pmf() function defined in the session on convolutions to use this continuous distribution with the discrete renewal equation.

To approximate the generation time PMF using random draws from the underlying continuous distribution use

gen_time_pmf <- censored_delay_pmf(rgamma, max = 14, shape = 4, rate = 1)

The discrete renewal equation is only valid for generation times greater than 0 so we remove the first element of the pmf and re-normalise:

gen_time_pmf <- gen_time_pmf[-1] ## remove first element
gen_time_pmf <- gen_time_pmf / sum(gen_time_pmf) ## renormalise

As always we first load the stan model and spend some time trying to understand it.

r_mod <- nfidd_cmdstan_model("estimate-r")
r_mod
 1: functions {
 2:   #include "functions/renewal.stan"
 3: }
 4:
 5: data {
 6:   int n;                // number of days
 7:   int I0;              // number initially infected
 8:   array[n] int obs;     // observed infections
 9:   int gen_time_max;     // maximum generation time
10:   array[gen_time_max] real gen_time_pmf;  // pmf of generation time distribution
11: }
12:
13: parameters {
14:   array[n] real<lower = 0> R;
15: }
16:
17: transformed parameters {
18:   array[n] real infections = renewal(I0, R, gen_time_pmf);
19: }
20:
21: model {
22:   // priors
23:   R ~ normal(1, 1) T[0, ];
24:   obs ~ poisson(infections);
25: }
Take 5 minutes

Familiarise yourself with the model above. Again there is a functions block at the beginning of the model (lines 1-3), where we load a function called renewal() (line 2) from a file of the same name which can be found in the subdirectory functions of the stan directory or viewed on the github repo. The functions correspond exactly to our earlier R function of the same name. Later, this function is called in the model block, to generate the time series of infections using the discretised renewal model (line 19). Which line defines priors, and which the likelihood?

Line 24 defines the prior distribution of \(R_t\) at each time point, and Line 25 defines the likelihood using Poisson observation uncertainty.

Once again we can generate estimates from this model:

data <- list(
  n = nrow(inf_ts) - 1,
  obs = inf_ts$infections[-1],
  I0 = inf_ts$infections[1],
  gen_time_max = length(gen_time_pmf),
  gen_time_pmf = gen_time_pmf
)
r_fit <- r_mod$sample(data = data, parallel_chains = 4)
r_fit
 variable     mean   median   sd  mad       q5      q95 rhat ess_bulk ess_tail
     lp__ 22088.03 22088.30 8.36 8.30 22073.50 22101.30 1.00     1816     2774
     R[1]     1.41     1.32 0.83 0.88     0.19     2.91 1.00     2543     1483
     R[2]     2.04     2.00 0.80 0.80     0.79     3.42 1.00     3454     1675
     R[3]     1.54     1.49 0.84 0.88     0.26     3.00 1.00     2398     1067
     R[4]     2.26     2.24 0.77 0.78     1.06     3.59 1.00     3774     2193
     R[5]     1.87     1.83 0.75 0.77     0.69     3.19 1.00     3783     1498
     R[6]     1.78     1.73 0.77 0.78     0.61     3.11 1.00     3555     1729
     R[7]     1.68     1.61 0.76 0.79     0.53     3.01 1.00     3785     1779
     R[8]     2.27     2.22 0.72 0.73     1.15     3.54 1.00     4767     2448
     R[9]     1.14     1.04 0.71 0.75     0.15     2.45 1.00     2518     1213

 # showing 10 of 283 rows (change via 'max_rows' argument or 'cmdstanr_max_rows' option)

Once stan has run its chains, we can visualise the posterior estimates.

# Extract posterior draws
r_posterior <- r_fit |>
  gather_draws(R[infection_day]) |>
  ungroup() |>
  mutate(infection_day = infection_day - 1) |>
  filter(.draw %in% sample(.draw, 100))

ggplot(
  data = r_posterior,
  aes(x = infection_day, y = .value, group = .draw))  +
  geom_line(alpha =  0.1) +
  labs(title = "Estimated Rt",
       subtitle = "Model 1: renewal equation from infections")

Take 10 minutes

Simulate from the renewal equation using the renewal() R function we defined above with a given \(R_t\) trajectory. For example, you could look at \(R_t\) increasing steadily, or suddenly, or having any other trajectory you might imagine. Use the stan model to infer the trajectory of the reproduction number from the resulting time series of infection. Does the model reproduce the simulated \(R_t\) trajectories?

Estimating \(R_t\) from a time series of symptom onsets

Epidemiological data is rarely, perhaps never, available as a time series of infection events. Instead, we usually observe outcomes such as symptom onsets when individuals interact with the health system, e.g. by presenting to a hospital. In the session on convolutions we simulated symptom onsets from a time series of infections by convolving with a delay and then sampling from a Poisson distribution: For this we used the convolved_with_delay() function.

We then simulate observations again using:

ip_pmf <- censored_delay_pmf(rgamma, max = 14, shape = 5, rate = 1)
onsets <- convolve_with_delay(inf_ts$infections, ip_pmf)
obs <- rpois(length(onsets), onsets)

We now add this to our renewal equation model and use this to estimate infections as well as the reproduction number:

r_inf_mod <- nfidd_cmdstan_model("estimate-inf-and-r")
r_inf_mod
 1: functions {
 2:   #include "functions/convolve_with_delay.stan"
 3:   #include "functions/renewal.stan"
 4: }
 5:
 6: data {
 7:   int n;                // number of days
 8:   int I0;              // number initially infected
 9:   array[n] int obs;     // observed symptom onsets
10:   int gen_time_max;     // maximum generation time
11:   array[gen_time_max] real gen_time_pmf;  // pmf of generation time distribution
12:   int<lower = 1> ip_max; // max incubation period
13:   array[ip_max + 1] real ip_pmf;
14: }
15:
16: parameters {
17:   array[n] real<lower = 0> R;
18: }
19:
20: transformed parameters {
21:   array[n] real infections = renewal(I0, R, gen_time_pmf);
22:   array[n] real onsets = convolve_with_delay(infections, ip_pmf);
23: }
24:
25: model {
26:   // priors
27:   R ~ normal(1, 1) T[0, ];
28:   obs ~ poisson(onsets);
29: }
Take 5 minutes

Familiarise yourself with the model above. Compare it to the model used earlier in this session, and the one used in the session on convolutions. Does this model have more parameters? How do the assumptions about the infections time series differ between the models?

We then generate estimates from this model:

data <- list(
  n = length(obs) - 1,
  obs = obs[-1],
  I0 = inf_ts$infections[1],
  gen_time_max = length(gen_time_pmf),
  gen_time_pmf = gen_time_pmf,
  ip_max = length(ip_pmf) - 1,
  ip_pmf = ip_pmf
)
r_inf_fit <- r_inf_mod$sample(
  data = data, parallel_chains = 4, init = \() list(init_R = 0)
)
Note

Generally one should start MCMC samplers with multiple different starting values to make sure the whole posterior distribution is explored. When testing this model we noticed that sometimes the model failed to fit the data at all. Because of this we added an argument to start sampling with init_R set to 0. This makes sure the sampler starts fitting the model from a sensible value and avoids fitting failiures.

r_inf_fit
 variable     mean   median   sd  mad       q5      q95 rhat ess_bulk ess_tail
     lp__ 21912.22 21912.40 9.74 9.79 21895.90 21927.60 1.01     1248     1896
     R[1]     1.41     1.33 0.82 0.86     0.22     2.86 1.00     2971     1767
     R[2]     1.61     1.56 0.85 0.90     0.30     3.08 1.00     2263     1098
     R[3]     1.72     1.69 0.85 0.91     0.39     3.17 1.00     3055     1457
     R[4]     1.72     1.70 0.86 0.89     0.37     3.21 1.00     2324     1164
     R[5]     1.71     1.66 0.86 0.88     0.38     3.22 1.00     2945     1718
     R[6]     1.68     1.64 0.85 0.90     0.32     3.13 1.00     1293      486
     R[7]     1.72     1.66 0.85 0.89     0.37     3.19 1.00     2188     1010
     R[8]     1.91     1.88 0.85 0.87     0.56     3.37 1.00     2065      941
     R[9]     1.49     1.45 0.80 0.85     0.26     2.86 1.00     2395     1319

 # showing 10 of 424 rows (change via 'max_rows' argument or 'cmdstanr_max_rows' option)

This time we can extract both the infections and R variables by infection day.

r_inf_posteriors <- r_inf_fit |>
  gather_draws(infections[infection_day], R[infection_day]) |>
  ungroup() |>
  mutate(infection_day = infection_day - 1) |>
  filter(.draw %in% sample(.draw, 100))

We can visualise infections compared to the data used to generate the time series of onsets

inf_posterior <- r_inf_posteriors |>
  filter(.variable == "infections")
ggplot(inf_posterior, mapping = aes(x = infection_day)) +
  geom_line(mapping = aes(y = .value, group = .draw), alpha = 0.1) +
  geom_line(
    data = inf_ts, mapping = aes(y = infections), colour = "red"
  ) +
  labs(title = "Infections, estimated (grey) and observed (red)",
       subtitle = "Model 2: renewal equation from symptom onsets")

and reproduction numbers

r_inf_posterior <- r_inf_posteriors |>
  filter(.variable == "R")
ggplot(
  r_inf_posterior, mapping = aes(x = infection_day, y = .value, group = .draw)
) +
  geom_line(alpha = 0.1)

Improving the generative model for the reproduction number

In the model so far we have assumed that the reproduction number at any time point is independent of the reproduction number at any other time point. This assumption has resulted in the quite noisy estimates of the reproduction number that we have seen in the plots above.

In reality, we might expect the reproduction number to change more smoothly over time (except in situations of drastic change such as a very effective intervention) and to be more similar at adjacent time points. We can model this by assuming that the reproduction number at time \(t\) is a random draw from a normal distribution with mean equal to the reproduction number at time \(t-1\) and some standard deviation \(\sigma\). This can be described as a random walk model for the reproduction number. In fact, rather than using this model directly, a better choice might be to use a model where the logarithm of the reproduction number does a random walk, as this will ensure that the reproduction number is always positive and that changes are multiplicative rather than additive (i.e as otherwise the same absolute change in the reproduction number would have a larger effect when the reproduction number is small which likely doesn’t match your intuition for how outbreaks evolve over time). We can write this model as

\[ \sigma \sim HalfNormal(0, 0.05) \\ \] \[ \log(R_0) \sim \mathcal{Lognormal}(-0.1, 0.5) \] \[ \log(R_t) \sim \mathcal{N}(\log(R_{t-1}), \sigma) \]

Here we have placed a prior on the standard deviation of the random walk, which we have assumed to be half-normal (i.e., normal but restricted to being non-negative) with a mean of 0 and a standard deviation of 0.05. This is a so-called weakly informative prior that allows for some variation in the reproduction number over time but not an unrealistic amount. We have also placed a prior on the initial reproduction number, which we have assumed to be log-normally distributed with a mean of -0.1 and a standard deviation of 0.5. This is a weakly informative prior that allows for a wide range of initial reproduction numbers but has a mean of approximately 1. The last line is the geometric random walk.

Simulating a geometric random walk

You can have a look at an R function for performing the geometric random walk:

geometric_random_walk
function (init, noise, std)
{
    n <- length(noise) + 1
    x <- numeric(n)
    x[1] <- init
    for (i in 2:n) {
        x[i] <- x[i - 1] + noise[i - 1] * std
    }
    return(exp(x))
}
<bytecode: 0x55a7572295a0>
<environment: namespace:nfidd>
Take 5 minutes

Look at this function and try to understand what it does. Note that we use the fact that we can generate a random normally distributed variable \(X\) with mean 0 and standard deviation \(\sigma\) by mutiplying a standard normally distributed variable (i.e., mean 0 and standard deviation 1) \(Y\) with \(\sigma\). Using this non-centred parameterisation for efficiency) will improve our computational efficency later when using an equivalent function in stan

We can use this function to simulate a random walk:

R <- geometric_random_walk(init = 1, noise = rnorm(100), std = 0.1)
data <- tibble(t = seq_along(R), R = exp(R))

ggplot(data, aes(x = t, y = R)) +
  geom_line() +
  labs(title = "Simulated data from a random walk model",
       x = "Time",
       y = "R")

You can repeat this multiple times either with the same parameters or changing some to get a feeling for what this does.

Estimating \(R_t\) with a geometric random walk prior

We can now include this in a stan model,

rw_mod <- nfidd_cmdstan_model("estimate-inf-and-r-rw")
rw_mod
 1: functions {
 2:   #include "functions/convolve_with_delay.stan"
 3:   #include "functions/renewal.stan"
 4:   #include "functions/geometric_random_walk.stan"
 5: }
 6:
 7: data {
 8:   int n;                // number of days
 9:   int I0;              // number initially infected
10:   array[n] int obs;     // observed symptom onsets
11:   int gen_time_max;     // maximum generation time
12:   array[gen_time_max] real gen_time_pmf;  // pmf of generation time distribution
13:   int<lower = 1> ip_max; // max incubation period
14:   array[ip_max + 1] real ip_pmf;
15: }
16:
17: parameters {
18:   real init_R;         // initial reproduction number
19:   array[n-1] real rw_noise; // random walk noise
20:   real<lower = 0> rw_sd; // random walk standard deviation
21: }
22:
23: transformed parameters {
24:   array[n] real R = geometric_random_walk(init_R, rw_noise, rw_sd);
25:   array[n] real infections = renewal(I0, R, gen_time_pmf);
26:   array[n] real onsets = convolve_with_delay(infections, ip_pmf);
27: }
28:
29: model {
30:   // priors
31:   init_R ~ normal(-.1, 0.5); // Approximately Normal(1, 0.5)
32:   rw_noise ~ std_normal();
33:   rw_sd ~ normal(0, 0.05) T[0,];
34:   obs ~ poisson(onsets);
35: }

Note that the model is very similar to the one we used earlier, but with the addition of the random walk model for the reproduction number using a function in stan that does the same as our R function of the same name we defined.

We can now generate estimates from this model:

data <- list(
  n = length(obs) - 1,
  obs = obs[-1],
  I0 = inf_ts$infections[1],
  gen_time_max = length(gen_time_pmf),
  gen_time_pmf = gen_time_pmf,
  ip_max = length(ip_pmf) - 1,
  ip_pmf = ip_pmf
)
r_rw_inf_fit <- rw_mod$sample(
  data = data, parallel_chains = 4, max_treedepth = 12,
  init = \() list(init_R = 0, rw_sd = 0.01)
)
r_rw_inf_fit
    variable     mean   median   sd  mad       q5      q95 rhat ess_bulk
 lp__        21883.73 21884.10 8.88 8.75 21868.20 21897.80 1.00     1654
 init_R          0.44     0.44 0.13 0.13     0.23     0.65 1.00     2231
 rw_noise[1]     0.12     0.12 1.00 0.99    -1.53     1.79 1.00     5591
 rw_noise[2]     0.07     0.08 1.02 1.02    -1.58     1.74 1.00     4923
 rw_noise[3]     0.02     0.02 1.00 1.00    -1.61     1.69 1.00     5155
 rw_noise[4]     0.03     0.06 0.98 0.96    -1.59     1.59 1.00     5091
 rw_noise[5]    -0.02    -0.03 0.99 0.97    -1.64     1.66 1.00     5044
 rw_noise[6]    -0.07    -0.08 0.99 0.98    -1.69     1.61 1.00     4715
 rw_noise[7]    -0.12    -0.12 0.99 0.95    -1.76     1.54 1.00     5183
 rw_noise[8]    -0.18    -0.17 0.99 0.98    -1.83     1.45 1.00     4776
 ess_tail
     2445
     2216
     2873
     2951
     3412
     2644
     3080
     2878
     2738
     2713

 # showing 10 of 566 rows (change via 'max_rows' argument or 'cmdstanr_max_rows' option)
Note

As this is a more complex model we have increased the max_treedepth parameter to 12 to allow for more complex posterior distributions and we have also provided an initialisation for the init_R and rw_sd parameters to help the sampler find the right region of parameter space. This is a common technique when fitting more complex models and is needed as it is hard a priori to know where the sampler should start.

We can again extract and visualise the posteriors in the same way as earlier.

rw_posteriors <- r_rw_inf_fit |>
  gather_draws(infections[infection_day], R[infection_day]) |>
  ungroup() |>
  mutate(infection_day = infection_day - 1) |>
  filter(.draw %in% sample(.draw, 100))
rw_inf_posterior <- rw_posteriors |>
  filter(.variable == "infections")
ggplot(mapping = aes(x = infection_day)) +
  geom_line(
    data = rw_inf_posterior, mapping = aes(y = .value, group = .draw), alpha = 0.1
  ) +
  geom_line(data = inf_ts, mapping = aes(y = infections), colour = "red") +
  labs(title = "Infections, estimated (grey) and observed (red)",
       subtitle = "Model 3: renewal equation with random walk")

and reproduction numbers

rw_r_inf_posterior <- rw_posteriors |>
  filter(.variable == "R") |>
  filter(.draw %in% sample(.draw, 100))
ggplot(
  data = rw_r_inf_posterior,
  mapping = aes(x = infection_day, y = .value, group = .draw)
) +
  geom_line(alpha = 0.1) +
  labs(title = "Estimated R",
       subtitle = "Model 3: renewal equation with random walk")

Take 10 minutes

Compare the results across the models used in this session, and the one used in the session on convolutions. How do the models vary in the number of parameters that need to be estimated? How do the assumptions about the infections time series differ between the models? What do you notice about the level of uncertainty in the estimates of infections and \(R_t\) over the course of the time series? If you have time you could try re-running the experiment with different \(R_t\) trajectories and delay distributions to see whether results change.

We can see that using the renewal model as generative model we recover the time series of infections more accurately compared to previously when we assumed independent numbers of infections each day and that using a more believable model (i.e the geometric random walk) for the reproduction number improves things even more. Of course, this is helped by the fact that the data was generated by a model similar to the renewal model used for inference.

Comparing the \(R_t\) trajectories

## earlier posteriors
r_posterior <- r_posterior |>
  mutate(data = "infections")
r_inf_posterior <- r_inf_posterior |>
  mutate(data = "onsets (normal)")
rw_r_inf_posterior <- rw_r_inf_posterior |>
  mutate(data = "onsets (random walk)")

all_posteriors <- rbind(
  r_inf_posterior,
  rw_r_inf_posterior,
  r_posterior
)

ggplot(
  all_posteriors,
  mapping = aes(x = infection_day, y = .value, group = .draw,
                colour = data)
) +
  geom_line(alpha = 0.1) +
  scale_fill_brewer(palette = "Set1") +
  labs(
    title = "Rt estimates from renewal equation models",
    subtitle = paste(
      "Estimates from infections, from symptom onsets, and from onsets with a",
      "random walk"
    )
  ) +
  guides(colour = guide_legend(override.aes = list(alpha = 1)))

We can see that the estimates are smoother when using the random walk model for the reproduction number, compared to the normal model. The model that fits directly to infections has the lowest uncertainty, which we would expect as it doesn’t have to infer the number of infections from symptom onsets but even here the reproduction number estimates are unrealistically noisy due to the assumption of independence between infections each day.

Going further

  • We have used symptom onsets under the assumption that every infected person develops symptoms. Earlier we also created a time series of hospitalisation under the assumption that only a proportion (e.g., 30%) of symptomatic individuals get hospitalised. How would you change the model in this case? What are the implications for inference?
  • The EpiNow2 package implements a more complex version of the model we have used here. You will have the opportunity to try it in a later session.
